OP Mode Select Encoder 1pcs 6020706-2

6020706-2
6020706
Ultrasound
LOGIQ S8
GE HealthCare
Outright
Add to Wish List
Login To Shop
Login To Shop
Please select date
Second Opinion Approval Needed

Enter your approval number and submit to add item(s) to cart.

Approval Number

Please enter approval number

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without the
approval number, GE will contact you before your order
can be confirmed for shipment.

Second Opinion Approval Needed

Select your approver's name and submit to add item(s) to your cart

Approver Name

Please Select Approver Name

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without
selecting an approver, GE will contact you before your order
can be confirmed for shipment.


Features

  • RoHS compliant
  • Precise
  • High resolution
  • Durable

Product Overview

The Optical Double Shaft Encoders are used in places where a higher degree of precision is needed. It can also be used in the applications, which requires a combination of resolution and durability. The optical double shaft encoder is an electro mechanical device that converts the circular or linear movement of shaft to digital signals. They are used to monitor or control variables such as direction, rate, speed, distance and position. The double shaft encoder has a /4 inch shaft with 25 detent positions and a 1/8 inch non-rotatable shaft. The 1/4 inch shaft connected with encoder is used to transfer rotary movement to the encoder and 1/8 inch non-rotatable shaft is intended to act as a pushbutton. LOT code with date of manufacture along with month and year is labelled in side of the encoder for easy identification. Rotary and pushbutton lifetime requirements are 1 million cycles respectively. These encoders are being used in MR Signa Optima HDxt 23 1.5T, UL LOGIQ E9, XV Innova 4100, UL LOGIQ 700, UL VOLUSON S6 and in many other systems.

Compatible Products

LOGIQ S8

LOGIQ S8

Substitute Parts :

Below is more information on the equivalent parts. Parts without a hyperlink are listed for reference only and are not available for purchase online.

Equivalent partPart Details
6020706

6020706
