Compact PS2 Barcode Scanner Cable
2055394-001
2055393-004
Diagnostic ECG
GE Healthcare
Outright
Add to Wish List
Login To Shop
Login To Shop
Please select date
Second Opinion Approval Needed

Enter your approval number and submit to add item(s) to cart.

Approval Number

Please enter approval number

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without the
approval number, GE will contact you before your order
can be confirmed for shipment.

Second Opinion Approval Needed

Select your approver's name and submit to add item(s) to your cart

Approver Name

Please Select Approver Name

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without
selecting an approver, GE will contact you before your order
can be confirmed for shipment.


Features

  • Reduces mechanical stress
  • Double-ended assembly provides variety of application
  • Used for data communications
  • Shielded housings prevents accidental disconnects

Product Overview

The Compact PS2 Barcode Scanner Cable is a component of the bar code scanner, which is a hand held device capable of reading linear (1D) and matrix (2D) bar codes. The PS/2 barcode scanner cable connects barcode reader to a computer keyboard, to transmit bar code data if it had been typed. One end of the cable is a 10 pin shielded modular plug used to connect barcode reader and the other end is a 6-pin mini-DIN connector used for connecting compatible computer keyboard system. These crimp plugs are designed to work with stranded cable and are easy to terminate. This cable is over molded to provide strain or bend relief. The cable shield is terminated at the connector end to ensure electrical contact between the cable and connector shield. The round shielded cables use twisted pair wiring, where two conductors are twisted together to improve electrical noise immunity. The scanner comes as a part of ARC MRI Monitor, MS DASH 4000, ARC Engstrom Carestation and MIC Giraffe™ OmniBed.

Compatible Products

MAC 5000

MAC 5000

MAC 3500

MAC 3500

MAC 5500

MAC 5500

Substitute Parts :

Below is more information on the equivalent parts. Parts without a hyperlink are listed for reference only and are not available for purchase online.

Equivalent partPart Details
2055393-004

2055393-004
